VOS3000 Debug Trace: Complete Call Signaling Analysis & Troubleshooting Guide

VOS3000 debug trace is an essential tool for diagnosing and resolving VoIP signaling issues. When calls fail, registrations don’t complete, or audio problems occur, the debug trace function provides detailed visibility into SIP and H.323 message flows, enabling administrators to pinpoint root causes quickly. This comprehensive guide covers all debug trace features based on official VOS3000 2.1.9.07 documentation.

📞 Need help with VOS3000 troubleshooting? WhatsApp: +8801911119966

🔍 Understanding VOS3000 Debug Trace

Reference: VOS3000 2.1.9.07 Manual, Section 2.17.1 (Page 205)

The debug trace function in VOS3000 captures all signaling messages processed by the softswitch, including SIP INVITE, REGISTER, BYE messages and H.323 signaling. This provides a complete record of call flows for troubleshooting and analysis.

📊 What Debug Trace Captures (VOS3000 Debug Trace)

Protocol	Messages Captured	Use Cases
SIP	INVITE, REGISTER, BYE, CANCEL, OPTIONS, 1xx/2xx/3xx/4xx/5xx/6xx responses	Call setup failures, registration issues, NAT problems
H.323	Setup, CallProceeding, Alerting, Connect, ReleaseComplete, H.245 messages	Gateway interconnection, codec negotiation
RTP	Media stream information (limited)	Audio path verification, codec confirmation

⚙️ Enabling Debug Trace

Reference: VOS3000 2.1.9.07 Manual, Section 2.17.1 (Page 205)

📍 Access Location

Navigate to: System > Debug trace in the VOS3000 client menu.

🔧 Debug Trace Configuration Options

Setting	Description	Recommendation
On/Off	Enable or disable trace capture	Enable only when troubleshooting
Trace Length	Duration to capture (in minutes)	Set specific duration or uncheck for continuous

Step-by-Step Debug Trace Activation:
====================================

1. Open VOS3000 Client

2. Navigate to:
   Menu bar > System > Debug trace

3. Configure Settings:
   ☑ Check "On" to enable trace
   ☐ Uncheck "Trace length" for continuous capture
   OR set specific duration (e.g., 30 minutes)

4. Click OK to start capture

5. Reproduce the problem:
   - Make test call
   - Attempt registration
   - Generate the issue you're investigating

6. View Trace Results:
   - Current Call: Right-click > Trace
   - CDR: Right-click > Call analysis

Important Notes:
================
- Trace impacts performance slightly when enabled
- Disable trace when not actively troubleshooting
- Trace files rotate automatically when size limit reached

📁 Trace File Management (VOS3000 Debug Trace)

Reference: VOS3000 2.1.9.07 Manual, Section 2.17.1 (Page 205) and Section 4.3.5.2 (Page 237-238)

⚙️ Trace File Parameters

Parameter	Default	Range	Description
SS_TRACE_FILE_LENGTH	40960	KB	Size of softswitch debug file (KB)
SS_TRACE_CALL_FILE_SIZE	16	16-2048 MB	Call signaling trace file size limit (MB)
SS_TRACE_REGISTER_FILE_SIZE	16	16-2048 MB	Registration signaling trace file size limit (MB)
SS_TRACE_MASK	ERROR	ERROR/DEBUG	Level of debug information to display
SS_TRACETOFILE	On	On/Off	Output debug information into file

📁 Two-File Rotation System

Reference: VOS3000 2.1.9.07 Manual, Section 2.17.1 (Page 205)

VOS3000 Trace File Rotation:
=============================

VOS3000 uses 2 files to record trace signaling:

File 1: trace1.log (or similar)
File 2: trace2.log (or similar)

How It Works:
=============
1. System writes to File 1
2. When File 1 reaches size limit (SS_TRACE_FILE_LENGTH)
3. System switches to File 2
4. When File 2 reaches size limit
5. System overwrites File 1 (oldest data lost)
6. Cycle continues...

Advantages:
===========
- Actual storage is double the file size limit
- Continuous capture without manual intervention
- Recent history always available
- Automatic cleanup of old data

Important:
==========
All trace signaling is saved unless file has been covered.
If you need to preserve trace data, copy files before rotation.

📊 Using Trace for Troubleshooting

📍 Accessing Trace Results (VOS3000 Debug Trace)

Reference: VOS3000 2.1.9.07 Manual, Section 2.17.1 (Page 205)

Access Method	Location	Information Shown
Current Call Trace	Current Call > Right-click > Trace	Real-time call signaling for active calls
CDR Call Analysis	CDR > Right-click > Call analysis	Complete signaling flow for completed call
Registration Analysis	Registration Management > Right-click	Registration message flow and status

🔧 Interpreting Trace Output (VOS3000 Debug Trace)

📊 SIP Message Format

Sample SIP INVITE Trace Output:
===============================

---------- 2026-04-03 10:25:32.123 ----------
INVITE sip:1234567890@192.168.1.100 SIP/2.0
Via: SIP/2.0/UDP 192.168.1.50:5060;branch=z9hG4bK123456
From: ;tag=12345
To:
Call-ID: abc123def456@192.168.1.50
CSeq: 1 INVITE
Contact:
Content-Type: application/sdp
Content-Length: 200

v=0
o=user 123 456 IN IP4 192.168.1.50
s=Session
c=IN IP4 192.168.1.50
t=0 0
m=audio 10000 RTP/AVP 0 8 18
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:18 G729/8000

Key Headers to Analyze:
=======================
- Via: Message path and NAT information
- From/To: Caller and callee identities
- Call-ID: Unique call identifier
- Contact: Where to send responses
- SDP (body): Media negotiation details

📊 H.323 Message Format (VOS3000 Debug Trace)

Sample H.323 Setup Trace Output:
================================

---------- 2026-04-03 10:26:15.456 ----------
H.225 Setup Message:
  Protocol Identifier: 0.0.8.2250.0.4
  Source Address:
    IP: 192.168.1.50
    Port: 1720
  Destination Address:
    IP: 192.168.1.100
    Port: 1720
  Source Info:
    E164: 0987654321
  Destination Info:
    E164: 1234567890
  Active MC: FALSE
  Conference ID: 0x12345678...

Key Elements to Analyze:
========================
- Protocol Identifier: H.323 version
- Source/Destination: Endpoint addresses
- E164 numbers: Calling/called numbers
- Conference ID: Call identifier

🚨 Common Debugging Scenarios (VOS3000 Debug Trace)

📊 One-Way Audio Diagnosis

Trace Finding	Meaning	Solution
SDP shows private IP in c= line	NAT issue – endpoint behind NAT	Enable media proxy, check NAT settings
RTP port mismatch between INVITE and 200 OK	SDP negotiation problem	Check codec compatibility, port ranges
Contact header has wrong IP	SIP ALG interference	Disable SIP ALG on router

📊 Registration Failure Analysis (VOS3000 Debug Trace)

Trace Finding	Meaning	Solution
401 Unauthorized response	Authentication credentials required	Configure correct username/password
403 Forbidden response	Account locked or IP not allowed	Check account status, IP whitelist
No response to REGISTER	Network or firewall issue	Check SIP port 5060, firewall rules
Authentication retry exceeded	Wrong credentials repeatedly	Verify credentials, check for typos

📊 Call Drop Investigation (VOS3000 Debug Trace)

Trace Finding	Meaning	Solution
BYE at 30-second interval	NAT binding timeout	Increase NAT keepalive, disable SIP ALG
Session timer expiry	Session timer not refreshed	Check SS_SIP_SESSION_TTL setting
RTP timeout in trace	No media received for configured time	Check media path, SS_MEDIA_CHECK_TIMEOUT
503 Service Unavailable	Gateway overloaded or down	Check gateway status, line limits

⚙️ Advanced Trace Configuration

📊 Trace Mask Settings

Reference: VOS3000 2.1.9.07 Manual, Section 4.3.5.2 (Page 238)

Setting	Information Level	When to Use
ERROR	Errors and warnings only	Normal troubleshooting, production systems
DEBUG	Detailed debug information	Complex issues, development testing

⚙️ Performance Impact (VOS3000 Debug Trace)

Performance Considerations:
==========================

SS_TRACE_MASK = ERROR (Default):
- Minimal performance impact
- Captures only error conditions
- Suitable for production systems
- Adequate for most troubleshooting

SS_TRACE_MASK = DEBUG:
- Higher performance impact
- Captures all message details
- More disk space usage
- Use for complex debugging only

Recommendations:
================
1. Use ERROR level for normal operations
2. Switch to DEBUG only when needed
3. Disable trace when not troubleshooting
4. Monitor disk space on busy systems
5. Set appropriate file size limits

Production Guidelines:
======================
- Keep SS_TRACETOFILE = On (writes to file, not memory)
- Set SS_TRACE_FILE_LENGTH appropriately (40MB default)
- Use SS_TRACE_MASK = ERROR
- Disable during high-traffic periods if possible

📊 CDR End Reason Reference (VOS3000 Debug Trace)

Reference: VOS3000 2.1.9.07 Manual, Section 4.5 (Page 243-248)

When analyzing call failures, the end reason in CDR combined with trace provides complete information:

📋 Server-Side End Reasons (VOS3000 Debug Trace)

End Reason	Description	Trace Analysis
Response timeout	No answer before timeout	Check INVITE sent, no 180/183/200 received
Connection timeout	No SIP response after retries	Check INVITE sent, check network path
Account locked	Account disabled	403 Forbidden in trace
Session timeout	Session timer expired	Check UPDATE/re-INVITE messages
No matching rate	No rate for destination	Call rejected before INVITE sent
Insufficient balance	Account out of funds	403 Forbidden after billing check
The called not online	No route available	No matching routing gateway

🔗 Related Resources (VOS3000 Debug Trace)

• 📖 Faster Support for VOS3000 Troubleshooting
• 📖 VOS3000 Softswitch FAQ
• 📖 NoAvailableRouter Error Troubleshooting
• 📖 SIP ALG Problems Troubleshooting Guide
• 📖 VOS3000 Downloads

❓ Frequently Asked Questions

Where are trace files stored?

Trace files are stored in the VOS3000 installation directory, typically under a “trace” or “log” subdirectory. The exact location depends on your installation path. The files are managed automatically by VOS3000’s two-file rotation system.

How long should I keep debug trace enabled?

Enable debug trace only when actively troubleshooting issues. For production systems, keep trace disabled or set to ERROR level to minimize performance impact. Enable DEBUG level only when investigating complex issues, then disable after resolution.

Can I export trace data for analysis?

Yes, you can use the call analysis feature in CDR to view detailed trace for specific calls. For bulk analysis, trace files can be copied from the server and analyzed with text editors or tools like Wireshark (for SIP traces saved in pcap format).

Why can’t I see trace for old calls?

Trace files have size limits and use rotation. When files exceed SS_TRACE_FILE_LENGTH or SS_TRACE_CALL_FILE_SIZE, older data is overwritten. If you need to preserve trace data for compliance or analysis, copy trace files before rotation occurs.

Does trace capture RTP media content?

No, VOS3000 debug trace captures signaling only (SIP and H.323). It does not capture the actual RTP media content (voice/audio). For media analysis, you would need separate packet capture tools like tcpdump or Wireshark on the server.
