💰 In VoIP wholesale routing, a gateway that is offline or unreachable is worse than no gateway at all. When VOS3000 routes a call to a dead gateway, the call fails, ASR drops, and your customers experience service interruptions. The VOS3000 SIP OPTIONS online check solves this by periodically sending SIP OPTIONS messages to detect whether each routing gateway’s SIP port is reachable. When the VOS3000 SIP OPTIONS online check detects a failure, it automatically switches to an alternative IP port, and if all ports fail, it marks the gateway as impossible until reachability is restored. Need help with gateway health monitoring? Contact us on WhatsApp at +8801911119966. 🔧
⚙️ According to the VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 43), the VOS3000 SIP OPTIONS online check is defined as: “Options online check: according to the soft switch system parameter ‘SS_SIP_OPTIONS_CHECK_PERIOD’ means sending SIP OPTIONS messages periodically to detect whether the SIP port of the routing gateway is reachable. When OPTIONS detection fails, it will switch to the IP port with successful OPTIONS detection. If all IP and ports fail, the routing gateway is impossible until the subsequent OPTIONS detection is successful.” The VOS3000 SIP OPTIONS online check provides reliable gateway health monitoring through automated SIP signaling.
🎯 This guide provides a complete, manual-verified reference for the VOS3000 SIP OPTIONS online check feature. All parameter definitions are sourced exclusively from the official VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 43). No fabricated values, no guesswork. For expert assistance, contact us on WhatsApp at +8801911119966. 📘
📋 The VOS3000 SIP OPTIONS online check is a gateway health monitoring feature that uses SIP OPTIONS messages to verify the reachability of routing gateway SIP ports. The SIP OPTIONS method is defined in RFC 3261 as a way to query the capabilities and availability of a SIP server or user agent. The VOS3000 SIP OPTIONS online check sends these messages periodically to each gateway and uses the response (or lack of response) to determine if the gateway is reachable.
💡 Key characteristics of VOS3000 SIP OPTIONS online check:
| Attribute | Detail |
|---|---|
| 📌 Feature Name | Options online check |
| 📝 Manual Description | “Options online check: according to the soft switch system parameter ‘SS_SIP_OPTIONS_CHECK_PERIOD’ means sending SIP OPTIONS messages periodically to detect whether the SIP port of the routing gateway is reachable. When OPTIONS detection fails, it will switch to the IP port with successful OPTIONS detection. If all IP and ports fail, the routing gateway is impossible until the subsequent OPTIONS detection is successful.” (VOS3000 V2.1.9.07 Manual §2.5.1.1, page 43) |
| 📍 Gateway Configuration | Routing gateway > Additional settings (SIP section) |
| ⏱️ System Parameter | SS_SIP_OPTIONS_CHECK_PERIOD — controls the interval between OPTIONS messages |
| 🔄 Failover Behavior | Switches to IP port with successful OPTIONS detection |
| 🚫 Failure Behavior | Gateway marked as impossible when all IP and ports fail |
🔧 The VOS3000 SIP OPTIONS online check operates as a periodic health monitoring system. At intervals defined by the SS_SIP_OPTIONS_CHECK_PERIOD system parameter, VOS3000 sends SIP OPTIONS messages to each routing gateway’s SIP port. The VOS3000 SIP OPTIONS online check evaluates the response to determine if the gateway is reachable.
| Step | Description |
|---|---|
| 1️⃣ OPTIONS message sent | VOS3000 sends SIP OPTIONS to the gateway’s SIP port at the configured interval |
| 2️⃣ Response evaluated | VOS3000 waits for a SIP response (200 OK, 503, timeout, etc.) |
| 3️⃣ Reachability determined | Successful response = gateway is reachable; no response or error = OPTIONS detection fails |
| 4️⃣ Auto-failover (if applicable) | If OPTIONS fails, VOS3000 SIP OPTIONS online check switches to another IP port with successful detection |
| 5️⃣ Gateway marking | If all IP and ports fail, the gateway is marked as impossible — calls won’t route to it |
| 6️⃣ Automatic recovery | When subsequent OPTIONS detection succeeds, the gateway is restored to possible status |
💡 Practical example: Gateway A has two IP:port combinations: 192.168.1.10:5060 and 192.168.1.11:5060. The VOS3000 SIP OPTIONS online check sends OPTIONS to 192.168.1.10:5060. If it receives a 200 OK, Gateway A is reachable via this IP. If 192.168.1.10 goes down, the VOS3000 SIP OPTIONS online check detects the failure, switches to 192.168.1.11:5060, and continues routing calls through the backup IP. If both IPs fail, Gateway A is marked as impossible until one of them responds to a subsequent OPTIONS check. The VOS3000 SIP OPTIONS online check provides seamless failover without manual intervention.
📊 The VOS3000 SIP OPTIONS online check manages gateway states based on OPTIONS detection results. Understanding these state transitions is essential for interpreting gateway behavior and troubleshooting connectivity issues.
| Gateway State | OPTIONS Result | Routing Behavior |
|---|---|---|
| ✅ Possible (Online) | At least one IP port responds to OPTIONS with success | Gateway is available for routing — calls are routed through the responding IP port |
| 🔄 Switching | Primary IP port fails OPTIONS, but alternative IP port succeeds | VOS3000 SIP OPTIONS online check switches to the responding IP port — calls continue |
| 🚫 Impossible (Offline) | All IP and ports fail OPTIONS detection | Gateway is excluded from routing — no calls are sent to it |
| 🔄 Recovery | Subsequent OPTIONS detection succeeds on any IP port | Gateway is restored to possible status — calls resume routing to it |
💡 Key insight: The VOS3000 SIP OPTIONS online check provides automatic recovery. When a gateway is marked as impossible because all IP ports failed OPTIONS detection, VOS3000 continues sending periodic OPTIONS messages. When any IP port responds successfully in a subsequent check, the VOS3000 SIP OPTIONS online check automatically restores the gateway to possible status. No manual intervention is required. For more on failover configuration, see our vendor failover setup guide.
🔗 The SS_SIP_OPTIONS_CHECK_PERIOD system parameter controls how frequently the VOS3000 SIP OPTIONS online check sends OPTIONS messages. This parameter is critical for balancing between fast failure detection and network overhead.
| Period Setting | Detection Speed | Network Overhead | Recommended For |
|---|---|---|---|
| Short (e.g., 10 seconds) | Fast — gateway failures detected quickly | Higher — more OPTIONS messages per gateway | 📊 Critical gateways where fast failover is essential |
| Medium (e.g., 30-60 seconds) | Moderate — failures detected within 1-2 minutes | Moderate — reasonable OPTIONS message volume | 🔧 Standard production environments |
| Long (e.g., 120+ seconds) | Slow — failures may take several minutes to detect | Lower — fewer OPTIONS messages | 💰 Stable gateways with rare failures |
💡 Configuration note: The SS_SIP_OPTIONS_CHECK_PERIOD is a system-level parameter that applies to all gateways with the VOS3000 SIP OPTIONS online check enabled. To configure this parameter, navigate to the system parameters section. For complete system parameter configuration, see our system parameters guide.
🔍 Symptom: The VOS3000 SIP OPTIONS online check marks a gateway as impossible even though the gateway is operational and can receive calls.
💡 Cause: The gateway may not respond to SIP OPTIONS messages. Some SIP servers and PBX systems do not implement the OPTIONS method and return error responses or drop OPTIONS requests entirely. The VOS3000 SIP OPTIONS online check interprets the lack of a successful response as a failure.
✅ Solutions:
🔍 Symptom: The VOS3000 SIP OPTIONS online check frequently switches between a gateway’s IP ports, causing intermittent routing instability.
💡 Cause: Network instability between VOS3000 and the gateway, or the gateway’s SIP service is intermittently unresponsive. The VOS3000 SIP OPTIONS online check detects these intermittent failures and switches back and forth between IP ports.
✅ Solutions:
🔍 Symptom: A gateway goes offline but VOS3000 continues routing calls to it, resulting in failed calls.
💡 Cause: The VOS3000 SIP OPTIONS online check may not be enabled on the gateway, or the SS_SIP_OPTIONS_CHECK_PERIOD may be too long, causing delayed failure detection.
✅ Solutions:
| Best Practice | Recommendation | Reason |
|---|---|---|
| 📊 Enable on all SIP gateways | Enable VOS3000 SIP OPTIONS online check on all SIP routing gateways | 🛡️ Ensures automatic failover when gateways become unreachable |
| 💰 Configure multiple IP ports | Add multiple IP:port combinations to each gateway for redundancy | 📋 Enables the VOS3000 SIP OPTIONS online check to switch between ports on failure |
| 🔄 Set appropriate check period | Configure SS_SIP_OPTIONS_CHECK_PERIOD based on your reliability requirements | 🔧 Balances fast failure detection against network overhead |
| 📞 Monitor impossible gateways | Regularly check for gateways marked as impossible by the VOS3000 SIP OPTIONS online check | 🔍 Identifies persistent gateway failures that need manual intervention |
| 📋 Verify gateway OPTIONS support | Confirm each gateway responds to SIP OPTIONS before enabling the check | 📊 Prevents false failures from gateways that do not support SIP OPTIONS |
🔗 The VOS3000 SIP OPTIONS online check works closely with the vendor failover mechanism. When the VOS3000 SIP OPTIONS online check marks a gateway as impossible, calls that would have been routed to that gateway are automatically redirected to other available gateways. This provides seamless failover without manual intervention.
| Failure Scenario | VOS3000 SIP OPTIONS Online Check | Failover Result |
|---|---|---|
| Primary IP port fails, backup succeeds | Switches to backup IP port automatically | ✅ Calls continue through backup IP — no failover to another gateway needed |
| All IP ports fail for one gateway | Gateway marked as impossible | 🔄 Calls failover to other available gateways in the route |
| All gateways for a destination fail | All gateways marked as impossible | 🚫 Call fails — no available routing path |
💡 Critical insight: The VOS3000 SIP OPTIONS online check provides two levels of failover. First, it switches between IP ports on the same gateway when one port fails. Second, when all ports fail, it enables gateway-level failover by excluding the gateway from routing and redirecting calls to other gateways. This two-tier failover approach maximizes call completion rates. The VOS3000 SIP OPTIONS online check is essential for any VoIP operation that requires high availability.
💰 The VOS3000 SIP OPTIONS online check is a gateway health monitoring feature that periodically sends SIP OPTIONS messages to detect whether each routing gateway’s SIP port is reachable. According to the VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 43), “Options online check: according to the soft switch system parameter ‘SS_SIP_OPTIONS_CHECK_PERIOD’ means sending SIP OPTIONS messages periodically to detect whether the SIP port of the routing gateway is reachable. When OPTIONS detection fails, it will switch to the IP port with successful OPTIONS detection. If all IP and ports fail, the routing gateway is impossible until the subsequent OPTIONS detection is successful.”
📊 The VOS3000 SIP OPTIONS online check sends OPTIONS messages at intervals defined by the SS_SIP_OPTIONS_CHECK_PERIOD system parameter. This parameter controls the period between OPTIONS checks for all gateways with the VOS3000 SIP OPTIONS online check enabled. A shorter period provides faster failure detection but generates more network traffic. A longer period reduces overhead but delays failure detection. Configure the SS_SIP_OPTIONS_CHECK_PERIOD based on your availability requirements and network capacity.
🔧 When the VOS3000 SIP OPTIONS online check detects a failure on a gateway’s IP port, it first attempts to switch to another IP port with successful OPTIONS detection. If an alternative IP port responds successfully, calls are automatically routed through that port. If all IP and ports fail, the VOS3000 SIP OPTIONS online check marks the gateway as impossible, and calls are redirected to other available gateways. The gateway remains impossible until a subsequent OPTIONS detection succeeds.
📋 The VOS3000 SIP OPTIONS online check is specific to SIP protocol gateways. SIP OPTIONS is a SIP method defined in RFC 3261 for querying SIP server availability. H323 gateways use a different protocol and do not support SIP OPTIONS. For H323 gateways, alternative health monitoring mechanisms would be needed. The VOS3000 SIP OPTIONS online check should only be enabled on SIP-based routing gateways.
📊 The network traffic generated by the VOS3000 SIP OPTIONS online check depends on the SS_SIP_OPTIONS_CHECK_PERIOD and the number of gateways. Each OPTIONS message is a small SIP packet (typically 200-400 bytes). For example, with 50 gateways and a 30-second check period, the VOS3000 SIP OPTIONS online check generates approximately 50 × 2 = 100 OPTIONS messages per minute (request + response), which is negligible for any modern network. The overhead of the VOS3000 SIP OPTIONS online check is minimal compared to the benefit of automatic failover.
🚫 Some SIP servers and PBX systems do not implement the SIP OPTIONS method and may return error responses (405 Method Not Allowed, 501 Not Implemented) or silently drop OPTIONS requests. The VOS3000 SIP OPTIONS online check may interpret these responses as failures, marking the gateway as impossible even though it can handle calls. If your gateway does not support SIP OPTIONS, you should disable the VOS3000 SIP OPTIONS online check on that specific gateway and use alternative monitoring methods. For help with this scenario, contact us on WhatsApp at +8801911119966.
🔧 The VOS3000 SIP OPTIONS online check is an essential gateway health monitoring feature that provides automatic failover and maximizes call completion rates. When configured correctly, the VOS3000 SIP OPTIONS online check detects gateway failures quickly, switches to backup IP ports automatically, and ensures calls are never routed to unreachable gateways. Whether you are implementing the VOS3000 SIP OPTIONS online check for the first time, tuning the check period, or troubleshooting false failures, expert guidance ensures your gateway monitoring is reliable and effective. 💰
