VOS3000 Period Dial Plan Restriction Complete Call Restriction Priority Setup
🔄 A single static dial plan or call restriction on a routing gateway cannot handle the reality of time-varying VoIP traffic. During business hours, you may want to allow all destinations through a premium gateway. After hours, you may need to block premium-rate numbers and reroute through a cheaper carrier. On weekends, an entirely different dial plan and priority structure may apply. The VOS3000 period dial plan restriction system provides three powerful per-gateway controls — Period Dial Plan, Period Call Restriction, and Period Priority — that allow you to define time-based rules for number transformation, call blocking, and gateway selection order. 🔧
⚙️ All three features are located under Additional settings > Period control in each routing gateway’s configuration panel. According to the VOS3000 V2.1.9.07 Manual §2.5.1.1 (pages 37–40), the VOS3000 period dial plan restriction system consists of three independent sub-panels: Period Dial Plan (page 37), Period Call Restriction (page 38), and Period Priority (page 40). Each sub-panel uses the same Weekdays / Begin time / End time framework but applies different rules — dial plans transform numbers, call restrictions block or allow specific prefixes, and priority changes the gateway’s selection order. Together, they create a comprehensive VOS3000 period dial plan restriction strategy that adapts to your traffic schedule. 📊
🎯 This guide provides a complete, manual-verified reference for all three VOS3000 period dial plan restriction features. All parameter definitions are sourced exclusively from the official VOS3000 V2.1.9.07 Manual §2.5.1.1 (pages 37–40). No fabricated values, no guesswork. For expert assistance, contact us on WhatsApp at +8801911119966. 📘
Table of Contents
🔐 What Is the VOS3000 Period Dial Plan Restriction System?
📋 The VOS3000 period dial plan restriction system is a collection of three per-gateway, time-based configuration features that control different aspects of call handling during specific time periods. Each feature is independently configured but shares the same Weekdays / Begin time / End time framework, allowing you to create coordinated time-based rules for gateway behavior.
💡 The three Period Control features:
- 📞 Period Dial Plan: Applies time-based dial plan (number transformation) rules per gateway — transforms caller or callee numbers during specific time windows
- 🚫 Period Call Restriction: Blocks or allows specific number prefixes during specific time periods — prevents calls to premium numbers after hours, for example
- 📊 Period Priority: Changes the gateway’s priority number during specific time periods — promotes or demotes the gateway in the selection order based on the schedule
📋 Period Dial Plan Reference
📞 The Period Dial Plan allows you to apply different dial plan rules to a routing gateway depending on the time of day and day of week. The VOS3000 period dial plan restriction feature for dial plans is documented in the VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 37).
| Field | Description | Manual Reference |
|---|---|---|
| 📅 Weekdays | Time corresponding to the week | §2.5.1.1, page 37 |
| ⏱️ Begin time | Time when the dial plan comes into effect | §2.5.1.1, page 37 |
| ⏱️ End time | Time when the dial plan expires | §2.5.1.1, page 37 |
| 📋 Mode | “The called” — the dial plan applies to the called number; “The caller” — the dial plan applies to the caller number | §2.5.1.1, page 37 |
| 📝 Dial plan | The content of the rule (the dial plan transformation to apply) | §2.5.1.1, page 37 |
💡 How the VOS3000 period dial plan restriction works for dial plans: When a call arrives and the current time matches a Period Dial Plan entry, the specified dial plan is applied to either the called number or the caller number (depending on the Mode setting). This allows you to, for example, strip area codes during off-peak routing or add tech prefixes during specific time windows. The dial plan transformation only applies when the call goes through this specific routing gateway during the defined period.
📋 Period Call Restriction Reference
🚫 The Period Call Restriction allows you to block or allow calls to specific number prefixes during defined time periods. The VOS3000 period dial plan restriction feature for call restrictions is documented in the VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 38).
| Field | Description | Manual Reference |
|---|---|---|
| 📅 Weekdays | Time corresponding to the week | §2.5.1.1, page 38 |
| ⏱️ Begin time | Time when the rule comes into effect | §2.5.1.1, page 38 |
| ⏱️ End time | Time when the rule expires | §2.5.1.1, page 38 |
| 🔄 Operation | Forbidden — blocks matched prefixes; Allow — permits matched prefixes | §2.5.1.1, page 38 |
| 📋 Mode | By callee — matches the prefixes of the callee numbers; By caller — matches the prefixes of the caller numbers | §2.5.1.1, page 38 |
| 🔢 Number prefix | The prefix of the number. Multiple prefixes can be specified, separated by commas | §2.5.1.1, page 38 |
💡 How the VOS3000 period dial plan restriction works for call restrictions: When a call arrives and the current time matches a Period Call Restriction entry, VOS3000 checks the caller or callee number against the specified prefixes. If the Operation is “Forbidden” and the number matches, the call is blocked from going through this gateway. If the Operation is “Allow” and the number does NOT match, the call is also blocked. This allows precise time-based access control — for example, blocking premium-rate prefixes (1900, 09xx) after business hours.
📋 Period Priority Reference
📊 The Period Priority allows you to change the routing gateway’s priority number during specific time periods. The VOS3000 period dial plan restriction feature for priority is documented in the VOS3000 V2.1.9.07 Manual §2.5.1.1 (page 40).
| Field | Description | Manual Reference |
|---|---|---|
| 📅 Weekdays | Time corresponding to the week | §2.5.1.1, page 40 |
| ⏱️ Begin time | Time when the rule comes into effect | §2.5.1.1, page 40 |
| ⏱️ End time | Time when the rule expires | §2.5.1.1, page 40 |
| 🔢 Priority | Priority for this gateway for this period | §2.5.1.1, page 40 |
💡 How the VOS3000 period dial plan restriction works for priority: In VOS3000, gateways with lower priority numbers are selected first (higher priority). The Period Priority feature allows you to dynamically change a gateway’s priority number based on the time of day. For example, you can set a cheaper gateway to priority 1 during off-peak hours (making it the first choice) and priority 10 during peak hours (making it a backup), while a premium gateway has the opposite schedule. The VOS3000 period dial plan restriction priority control enables cost-optimized routing that adapts to traffic demand.
📊 Three-Feature Comparison Table
| Aspect | Period Dial Plan | Period Call Restriction | Period Priority |
|---|---|---|---|
| 📋 Purpose | Transform numbers | Block/allow prefixes | Change selection order |
| 🔧 Action | Applies dial plan rewrite rule | Forbids or allows calls by prefix | Sets gateway priority number |
| 📋 Mode options | The called / The caller | By callee / By caller | Priority number only |
| 📊 Effect on call | Modifies the number sent to gateway | Prevents or permits the call | Changes when the gateway is tried |
| 📄 Manual page | Page 37 | Page 38 | Page 40 |
📊 Practical VOS3000 Period Dial Plan Restriction Configuration Scenarios
🎯 Here are practical deployment scenarios that demonstrate how the three VOS3000 period dial plan restriction features work together for comprehensive time-based traffic management:
| Scenario | Period Dial Plan | Period Call Restriction | Period Priority |
|---|---|---|---|
| 🏢 Business hours gateway | Strip local area code during 09:00–18:00 | Block premium prefixes (1900) after 18:00 | Priority 1 during 09:00–18:00, Priority 5 after hours |
| 💰 Cost-optimized routing | Add tech prefix during off-peak hours | Allow only domestic prefixes at night | Priority 1 during 00:00–08:00 (cheap route), Priority 8 during peak |
| 📞 Premium gateway for VIP | Rewrite caller ID for VIP customers | Allow only VIP customer prefixes | Priority 1 during business hours for VIP |
| 🌍 Weekend special routing | Apply weekend dial plan for Saturday/Sunday | Block international prefixes on weekends | Lower priority on weekends to reduce costs |
🛡️ Common VOS3000 Period Dial Plan Restriction Problems and Solutions
❌ Problem 1: Period Dial Plan Not Applying to Calls
🔍 Symptom: The VOS3000 period dial plan restriction is configured with a dial plan entry for a specific time period, but calls during that period still use the static dial plan instead of the period-specific one.
💡 Cause: The Mode field may be set incorrectly. If the VOS3000 period dial plan restriction is configured with Mode = “The called” but you want to transform the caller number, the dial plan will not apply to the correct number field.
✅ Solutions:
- 🔧 Verify the Mode setting matches your intent — “The called” for callee transformation, “The caller” for caller transformation
- 📊 Ensure the dial plan content is correctly defined in the dial plan management module
- 📋 Check that the Weekdays and time window match the current call time in the VOS3000 period dial plan restriction
❌ Problem 2: Call Restriction Blocking Too Many Calls
🔍 Symptom: The VOS3000 period dial plan restriction call restriction is blocking calls that should be allowed, affecting legitimate traffic during the configured time period.
💡 Cause: The Number prefix field may contain prefixes that are too broad. For example, blocking prefix “1” would block all numbers starting with 1, including valid domestic numbers, not just premium-rate numbers like “1900.”
✅ Solutions:
- 🔧 Use the most specific prefix possible — block “1900” instead of “1” in the VOS3000 period dial plan restriction
- 📊 Switch from “Forbidden” to “Allow” mode with explicit allowed prefixes for more precise control
- 📋 Test the VOS3000 period dial plan restriction during a low-traffic period to verify the correct calls are blocked
❌ Problem 3: Period Priority Not Changing Gateway Selection Order
🔍 Symptom: The VOS3000 period dial plan restriction priority is configured to change the gateway’s priority during a specific period, but the gateway selection order does not change as expected.
💡 Cause: Other gateways in the routing pool may have static priority numbers that still outrank the period-adjusted priority. The VOS3000 period dial plan restriction priority only changes this specific gateway’s priority — it does not affect other gateways’ priorities.
✅ Solutions:
- 🔧 Review the priority numbers of ALL gateways in the routing pool, not just the one with the VOS3000 period dial plan restriction
- 📊 Ensure the period priority value is set low enough (higher priority) to outrank competing gateways during the desired period
- 📋 Use the routing optimization guide to design a complete priority strategy
💡 VOS3000 Period Dial Plan Restriction Best Practices
🎯 Follow these best practices for effective VOS3000 period dial plan restriction deployment:
| Best Practice | Recommendation | Reason |
|---|---|---|
| 📋 Use specific prefixes for restrictions | Block “1900” not “1” in the VOS3000 period dial plan restriction | 🔧 Prevents accidentally blocking legitimate numbers |
| 📊 Coordinate all three features | Align dial plans, restrictions, and priority in the VOS3000 period dial plan restriction | 🔄 Creates a coherent time-based traffic management strategy |
| 📅 Cover full 24-hour day | Ensure no time gaps in the VOS3000 period dial plan restriction entries | 📋 Prevents unexpected behavior during uncovered time windows |
| 🧪 Test during low traffic | Deploy VOS3000 period dial plan restriction changes during off-peak hours | 📊 Minimizes impact if configuration has errors |
| 📞 Verify with CDR analysis | Check CDR analysis after deploying the VOS3000 period dial plan restriction | 📈 Confirms the VOS3000 period dial plan restriction is working as intended |
💬 Need VOS3000 period dial plan help? WhatsApp +8801911119966
❓ Frequently Asked Questions
❓ What is the VOS3000 period dial plan restriction?
📋 The VOS3000 period dial plan restriction is a system of three per-gateway, time-based configuration features — Period Dial Plan, Period Call Restriction, and Period Priority — that allow you to define different call handling rules for different time periods. Period Dial Plan transforms numbers during specific time windows. Period Call Restriction blocks or allows specific number prefixes during defined periods. Period Priority changes the gateway’s selection order based on the schedule. All three features are documented in the VOS3000 V2.1.9.07 Manual §2.5.1.1 (pages 37–40) and are configured under Additional settings > Period control in each routing gateway.
❓ What is the difference between Period Dial Plan and the static dial plan?
📞 The static dial plan (configured under Additional settings > Routing prefix) applies at all times regardless of the current time. The VOS3000 period dial plan restriction dial plan applies only during the defined time window and overrides the static dial plan for that period. When the period expires, the static dial plan becomes active again. This allows you to, for example, use one number transformation rule during business hours and a different rule after hours, all on the same gateway.
❓ Can I use Allow and Forbidden operations together in Period Call Restriction?
🚫 Each VOS3000 period dial plan restriction call restriction entry uses either Allow or Forbidden — you cannot combine both in a single entry. However, you can create multiple entries for different time periods, using Forbidden during one period and Allow during another. For example, you could create a Forbidden entry for premium prefixes (1900, 09xx) during 18:00–09:00 and an Allow entry for all domestic prefixes during 09:00–18:00. The VOS3000 period dial plan restriction supports multiple entries to create complex time-based access policies.
❓ How does Period Priority affect the routing selection?
📊 In VOS3000, gateway priority determines the order in which gateways are tried when multiple gateways match a destination prefix. Lower priority numbers are tried first (higher priority). The VOS3000 period dial plan restriction priority feature changes the gateway’s priority number during the defined period, effectively promoting or demoting the gateway in the selection order. For example, if a gateway has static priority 5 but a period priority of 1 during 00:00–08:00, it becomes the first-choice gateway during that time window. This enables cost-optimized routing where cheaper gateways are preferred during off-peak hours.
❓ Do all three Period Control features need to be configured together?
🔧 No, all three VOS3000 period dial plan restriction features are independent. You can configure only Period Dial Plan, only Period Call Restriction, only Period Priority, or any combination. Each feature operates independently based on its own time window configuration. For example, you might use only Period Priority on a gateway to change its selection order during peak hours, without any dial plan changes or call restrictions. The VOS3000 period dial plan restriction system is flexible and allows you to use exactly the features you need.
❓ Can different gateways have different period configurations?
📡 Yes, the VOS3000 period dial plan restriction is configured per-gateway. Each routing gateway has its own independent Period Dial Plan, Period Call Restriction, and Period Priority tables. This means Gateway A can have a business-hours dial plan for weekdays while Gateway B has a weekend-only restriction, and Gateway C has a different priority schedule entirely. This per-gateway flexibility in the VOS3000 period dial plan restriction system allows you to design complex, gateway-specific time-based policies. Need help designing your period control strategy? Contact us on WhatsApp at +8801911119966. 📱
